Strong anti-interference Network Dante receiver IO16CH Dante audio
Interface
Products Description:
This is our 16CH Dante Interface,DB series products are audio
interface devices based on Dante international general protocol,
which can input analog audio signals, convert them into digital
audio signals, and route them to any Dante audio transmission
network devices through Dante protocol, achieving features such as
high quality, long distance, low delay, strong anti-interference
ability, and convenient networking.
In addition, it supports access to any Dante network digital audio,
conversion to analog audio signal output, and access to traditional
analog audio devices such as mixing consoles, power amplifiers, and
processors.The device adopts high quality AD/DA signal conversion
chip, provides 48V phantom power supply, and can access higher
quality capacitor mic
Specification:
| Model No. | DB-0808,DB-1616 | Channel | DB-0808 (8 analog inputs, 8 analog outputs) + 8 × 8 Dante
DB-1616 (16 analog input, 16 analog output)+ 16 × 16 Dante |
| Sensitivity | 0dB ~ 51dB,3dB/level | Digitalizing bit | 24bit |
| Sampling rate | 48k | Frequency response (20~20KHz) | 20HZ ~ 20K HZ ,±0.5dB |
| Maximum input level (balanced) | 20dBu | Floor Noise | -90dBu |
| Maximum output level (balanced) | 20dBu | THD+N | ＜0.002% @ 4dBu |
| Analog to Digital dynamic range | 118dB | Digital to Analog dynamic range | 123dB |
| Input to output dynamic range | 110dB | Input impedance (balanced) | 20KΩ |
| Output impedance (balanced) | 100Ω | Input common mode rejection | 80dB @60Hz |
Application:
Products Front Panel Over View:
(1) Signal indicator, clipping indicator, phantom power supply
indicator;
(2) Power indicator, the light indicates that the power supply is
normal, otherwise the power supply is abnormal;
(3) Status indicator, blinking indicates that the equipment is
running normally, otherwise the equipment fails;
(4) TFT screen: embedded GUI display;
(5) EDIT: Embedded GUI control, click to enter editing state;
(6) BACK: embedded GUI control, return to the upper menu button;
(7) Control button: embedded GUI control, function selection and
parameter control button;
A) Left-right rotation: select functions, adjust parameters,
double-click to save the scene;
B) Click to select the current function.
C) Left and right rotation on the basis of B) : parameter
adjustment;
Products Back Panel Over View:
①12V DC power port
② Power switch
③Dante network interfaces
④ETHERNET: 10M/100M ETHERNET interface, used to connect the control
end (PC, router, etc.);
⑤RS232: central control command interface RX: receive data,TX: send
data,G: ground;
⑥ Input channel;
⑦ Output channel;
