CE ROHS certificated XLR input analog signal conversion 2CH Dante
Wall Plate dante audio
Main Features:
- Dante 2X2 wall panel for conversion between analog audio signal and
Dante digital audio signal.
- This device supports 2-channel analog input and 2-channel analog
output.
- This device supports 2 channels Dante input and 2 channels Dante
output.
- This device supports conversion of analog input to Dante digital
audio; Supports Dante digital audio to analog audio output.
- Each channel analog input, with phantom power supply switch, gain
manual adjustment knob.
- POE mode power supply, compatible with 802.3af, 802.3at standard
POE switches.
- Front panel independent power indicator
Description:
This product provides a signal connection between analog input and
output and Dante channel, requiring PoE network power supply.
DP22 supports two sets of balanced I/O analog signals to connect to
Dante system through local area network. The input interface use a
two-in-one XLR to provide phantom power switch and gain adjustment
function of input signal. The output interface is standard 3 Pin
XLR , output balanced analog signal.
Specification:
| Product Model No. | DP22 |
| Analog input channel | 2 |
| Analog output channel | 2 |
| Dante input channel | 2 |
| Dante output channel | 2 |
| Dante interface | 1 |
| Input gain amplification | Rotary gain knob (0 ~ 20dB) |
| Balanced/non-balanced, input/output support | √ |
| MICLINE, input/output support | √ |
| 48V phantom power switch | √ |
| Sampling rate | 48kHz |
| Phantom power | 48V |
| Frequency Response (20~20KHz) | 20Hz ～ 20K Hz,±0.5dB |
| THD+N | ≦0.005% @4dBu |
| Digital-analog dynamic range (A weighting) | 120dB |
| Analog - digital dynamic range (A weighting) | 114dB |
| Input impedance (balanced) | 20kΩ |
| Output impedance (balanced) | 100Ω |
| EIN(A weighting) | ≤-131 dBu |
| Channel isolation @1kHz | 100dB @1k Hz,4dBu |
| Simulated maximum gain | 20dB |
| Common-mode rejection | 80dB @80 Hz |
| Maximum input level | 18dBu |
| Maximum output level | 18dBu |
| Ground Noise | -90dBu |
| System delay | ≤3ms |
| Working Power Supply | PoE 48V |
| Operating temperature | '-10-50℃ |
| Size | 87*97*46(mm) |
FAQ:
Q1: Are you manufacturer or trade company?
A: We are manufacturer,which located in Shenzhen, Guangdong, China.
Q2: Do you offer OEM&ODM service?
A: Yes, We can provide OEM or ODM Solution depends on client
requirements
Q3: What's the quality standard of your products?
A: Our products has approved CE, ROHS certification.
Q4: Which place will use FHB equipment?
A: Our products are widely used in International Conference,
Governments, Banks, Churches, Airports, Parliaments, Education
institutes, Hotel, Private corporate conference hall etc,.
Q5: What’s the delivery time?
A:Sample order: During 5days,Bulk order:10-15days
Q5: Why choose FHB Audio Products?
A:Pls refer to below details:
FHB Audio is driven by innovation. We are continuously developing
new technologies that provide time saving methods that benefit you
and our dealer network. Our innovative solutions focus on everyday
use cases and how our products can cut down installation times,
reduce maintenance requirements, increase productivity, and provide
you long-lasting reliability.
- Wide & Deep Products Line
We provide over 200 audio & Video products, as well as a series of
Dante products, such as Digital Signal processor, Digital
microphone system,Dante signal processor, 2CH Dante AVUO,2CH Dante
wall plate,4CH Dante box., Dante Bluetooth panel, Dante microphone,
and Dante speaker etc…
Our industry-leading support team makes it easy for you to choose
the right product and provide the right system solutions.
- Professional & Fast Service,
- 24 hours online services to provide suggestions and solutions for
customer.
- After-Sales Technical Support /Product Maintenance
- Wiring/Installation/Debugging Instruction
Professional System Designers to assist in product selection and
system design to meet your specific needs.
Check Products one by one, to make sure all products are working
excellent quality..
