CE ROHS certificated PoE 2CH bluetooth Dante IO Audio Interface for
conference
BT22 is a two-way stereo transmission panel for Bluetooth and
Dante.It uses PoE power supply and wall installation. BT22 connects to mobile phones, ipad and other devices through
Bluetooth interface, and converts the received audio signal into
network digital signal transmission through Dante.Power, control,
and audio data are transmitted by network cables, and there is no
need to worry about ground loops or other audio issues.The main
applications are teleconferencing, audio media transmission and so
on.
|
Main Features:
- Easy to use, you can control Bluetooth pairing with one button,
connect the device, and display the connection status through LED
light.
- Good compatibility, it can be compatible with most smart phones,
Apple ipad and Android tablet, etc.
- Power supply and audio transmission integrated, adopt PoE power
supply, audio transmission through network cable
- Simple audio routing, configure audio routing through Dante
Controller.
- Support modify the Bluetooth name
Specification:
| Model No. | BT22 | | Bluetooth interface(MPT-III) | Bluetooth 5.0, Stereo I/O | | Dante interface | RJ45 interface, stereo input/output | Frequency response | 20Hz-20kHz | Sampling rate | 48kHz 24bit | | Floor noise | -90dB | | Power consumption | 2W | THD | <0.005% | Temperature | -10℃ ~ +40℃ | Humidity | 5%-95% | Size | 123.5mm×79mm×35mm | Weight | 156g |
|
System View:
Products Over View:
- ① :Red indicator: Power/Bluetooth disconnected
- ②:Blue indicator: Bluetooth connection is successful
- ③:Bluetooth pairing button
- ④:RJ45 Network Interface
Opration:
- ① Connect the equipment correctly
- ② Long press the PAIR button on the panel for about 3S, the red and
blue LED indicator lights start to flash alternately, it means that
it is visible to other devices and can receive pairing
- ③ Use Dante Controller software to control DANTE audio routing and
modify Bluetooth name
