Name: 8X8 Conference DSP Digital Processor Media Matrix For Hall Auditorium Public Sound System
Brand: FHB Audio
Price: 1 USD

Add to Cart

8X8 Digital Audio Matrix System Audio Processor Conference Media Matrix for Hall Auditorium,Public Sound System

Main Features:

Suitable for meeting room, campus, art performance, concert and other scene areas
Provide PC software and web control
System built-in lock screen function, can effectively avoid the wrong operation.
DSP audio processing, built-in automatic mixer, feedback elimination(AFS),AGC function
Input per channel: Front stage amplifier, signal generator, expander, compressor, 5 stage parameter equalization
Output per channel:31 Section diagram equalizer, delay device, frequency divider, limiter
Full function matrix remix
Built-in automatic camera tracking function
Support for scenario presets；
Automatic memory protection when power off
1U Whole aluminum chassis

Specification:

Product Technical Parameters
DSP Chip	Dual Core Ti 450MHz FLOPS
Centrally controlled instruction set generator	Support
Input Processing	Pre-amplifier, signal generator, extender, compressor, 5-segment parameter equalization, inversion, automatic gain, automatic mixing
Output Processing	Segment 31 shows equalizer, delay device, frequency divider, limiter, and inverting
Matrix Mixing	Input and output signal matrix mixing, mixing component control
Automatic camera tracking function	Support
Scene preset	100 groups of custom Settings
Sampling	48KHz
phantom power	48V
Frequency response	20 - 20K Hz,±0.2dB
THD+N	≦0.004% @4dBu
Digital to analog dynamic range (A Weighted)	120dB
Analog to Digital dynamic range (A Weighted)	114dB
Input Impedance (Balanced)	20kΩ
Output impedance (Balanced)	100Ω
EIN(A Weighted)	≤-120 dBu
Channel isolation	104dB @1k Hz
Common mode rejection	70dB @80 Hz
Maximum input level	18dBu
Maximum output level	18dBu
Floor Noise	-90dBu
Working Power	DC12V/2A
Size	48225845(mm)；
Net Weight	2.5kg
I/O
Model No.	MX-0808-C	MX-0808D-C	MX-1616-C
No. of analog input	8	8	16
No. of analog output	8	8	16
No. of Dante input	×	4	×
No. of Dante output	×	4	×
Ethernet	1	1	1
RS485	1	1	1
GPIO	2	2	2
Input gain amplification	-24～18dB,6dB,Total 7 level
Balanced/non-balanced,	Support
MICLINE	Support
Each independent 48V phantom power supply	Support
DSP Processing
AFC	√	√	√
AEC	×	×	×
ANC	×	×	×
AM	√	√	√
AGC	√	√	√
PC Software
PC Software	Support
Windows32位	Support
Windows64位	Support
client-side	Built-in client, support online download

Software:

Our designed PC version control software is the best tool for you to monitor and operate the digital audio processor, which can be used to edit and store scenes (such as meeting mode, artistic performance mode, concert mode, etc.) according to the acoustic characteristics of different functions. The system built-in lock screen function, It can effectively avoid the occurrence of wrong operation.
